Explosionproof & Dust-Ignition Proof Fittings and Accessories - Sealing Fittings XYB 40% Fill

• Sealing Fittings are required in Hazardous Locations and are used to isolate arcproducing devices in conduit and wiring systems, and to prevent the passage of explosive pressures from one area to another.

• FOR HORIZONTAL AND VERTICAL MOUNTING - Type XYB and XYBM are suitable for either horizontal or vertical mounting and are provided with threaded plugged openings into which fiber and cement can be placed to form effective seal.

XYB has female ends for conduit entrance. The XYBM has female ends with a removable threaded nipple.

• 40% Fill Fittings - Sealing Fittings are used for the same application as the standard Adalet sealing fitting but allow up to 40% wire fill in the fitting.
