Explosionproof Motor Control - Magnetic Motor Starter/Protector

• Motor starters are reversing or non-reversing and are rated 5HP to 200HP

• Through the door mechanical reset button

• Pre-drilled for hinges (hinges optional)

• Pre-drilled for sub-panel (sub-panel optional)

• One-piece, NEMA 4 water-tight gasket

• Premium, high-strength stainless steel captive cover bolts

• Internal grounding provisions

• Cast-on mounting feet

• Tumblast surface preparation for uniform, natural, aluminum finish

• Standard drilled & tapped conduit configurations

• Sub-Panels – Available in galvanized steel (XSM) or aluminum (XSA)

• Aluminum hinge kits (with stainless steel hardware)

• Non-removable hinges

• Customer specified drilling and tapping

• Installation of operators and auxiliary devices

• Custom machining – milling, counter-boring, spot-facing, blind-tapped holes, etc

• Installation and wiring of internal terminal blocks and control components

• UL Listed NNNY populated / wired control panels

• Multiple coating options for additional corrosion resistance

• Captive cover bolts

• Quad-lead cover bolts

• Auxiliary switches, breather/drain, shunt trip, under-voltage release, transformers, wiring

• Enclosures cast from proprietary 359 aluminum alloy

• Standard stainless steel cover bolts are 316L

• XSM panels are #12 gauge galvanized steel (.108” thick)

• XSA panels are #10 gauge aluminum (.100 thick)

• Hinge blocks are 359 aluminum, pins and hardware are 303 stainless steel
