ExplosionProof Operator Devices - Miniature Operators
ExplosionProof Operator Devices - Miniature Operators
We know safety is the number one priority in hazardous industrial locations. That’s why Adalet has developed a full line of explosion proof heavy-duty pilot lights, pushbuttons and selector switches with uncompromising attention to the highest safety standards.
Whether you need a pushbutton or an explosion proof switch, Adalet guarantees you a durable and dependable product, made to withstand even the harshest environments. Our engineering department is always available to assist you in developing custom products tailored to your application.
Standard Features
Standard Features
• Reduce size of control enclosure requirements in hazardous environments.
• Mount on 1” centers vs. standard operators requiring 2 1/2” centers.
• No special enclosures required; can be installed in most Adalet standard
explosionproof enclosures.
• 3/8”-16 UNC thread size body.
• Black anodized body, cap, button or knob
• Two lengths available: Long Series Accommodates up to 1 9/16”
enclosure wall thickness. Short Series Accommodates up to 13/16”
enclosure wall thickness
• Stainless steel actuator shaft.
• Optional red or green button (Pushbutton Operator only)
